ABS Grade AH40 ship plate owned the higher yield strength and tensile strength. ABS Grade AH 40 Shipbuilding Steel Plate are mainly used to contribute hull of ships and the cranes of break bulker and vessels in low temperature oceans.
Mechanical property for ABS Grade AH40 shipbuilding structural steel
Yield strength (≥Mpa) | Tensile strength (Mpa) | Elongation in ≥,% | |
390 | 510-650 | 200mm | 50mm |
19 | 22 |
Chemical composition for ABS Grade AH40 ship steel (Heat Analysis Max%)
Main chemical elements composition of ABS Grade AH40 | ||||||
C | Si | Mn | P | S | Al (acid) min. | Nb |
0.18 | 0.10-0.50 | 0.90-1.60 | 0.035 | 0.035 | 0.015 | 0.02-0.05 |
V | Ti | Cu | Cr | Ni | Mo | |
0.05-0.10 | 0.02 | 0.35 | 0.20 | 0.40 | 0.08 |
Thickness:6--200mm
Width:1500--4000mm
Length: 3000--12000 mm
We can supply any size based on customer΄s requirements
Width:1500--4000mm
Length: 3000--12000 mm
We can supply any size based on customer΄s requirements
♦High tension test
♦ Z-Test (Z15,Z25,Z35)
♦ Low temperature impacting test
♦ Ultrasonic test under ASTM A435,A577,A578
♦ Certificated by ABS,LR,GL,BV,DNV,KR,NK,CCS,RINA
♦ Issued Original Mill test certificate under EN 10204 FORMAT 3.1/3.2
♦ Shot blasting and Painting, Cutting and welding as per end user’s demands
♦ Z-Test (Z15,Z25,Z35)
♦ Low temperature impacting test
♦ Ultrasonic test under ASTM A435,A577,A578
♦ Certificated by ABS,LR,GL,BV,DNV,KR,NK,CCS,RINA
♦ Issued Original Mill test certificate under EN 10204 FORMAT 3.1/3.2
♦ Shot blasting and Painting, Cutting and welding as per end user’s demands
Shanghai Katalor Enterprises Co., Ltd is a big complex combined steel stockist whose business related with trade, processing, storage and transportation. we are specialized in supplying ABS Grade AH40 ship plate. We have the good quality and advanced equipment, our products meet the state standard, and also available for customers' requirement. If you have any need of ABS Grade AH 40 Shipbuilding Steel Plate , please do not hesitate to contact us by email info@katalor.com, we can do our best to help you!
